Caching Gatsby builds with Docker in GitHub Actions
At DoltHub, we write a lot of blogs. Each week our team publishes three to four blogs on various topics. Some recent blogs include our ongoing effort to publish Hospital Price Data in a single, coherent database, the release of Dolt v0.75.0 which includes support for Spatial Indexes and ACID transactions, and Type Embedding in Golang.
To create a new blog post for our site, a team member writes a markdown file and checks it in to our blog source directory. The content in this directory is served by Gatsby and we deploy our Gatsby blog app inside a Docker container running on a Kubernetes host.
Luckily for our team, the hardest part of creating a new blog post is writing it. But, the most annoying part about publishing the blog post is waiting FOREVER for the thing to deploy.
Our team members can trigger a blog deployment to our development and production sites by commenting on the pull request containing their new post, like so:
#deploy [blog]This comment triggers a GitHub Actions workflow that builds and deploys their changes. Now, although it's fast to trigger a deployment, it used to take up to 30 minutes to actually see the deployment live. Most of this time was spent running gatsby build.
This was a real pain point. Anytime team members had typos or suggested changes they needed to incorporate into their drafts, they'd have to wait 30 minutes for each iteration of changes to go out.
You can imagine how frustrating it would be to experience this three to four times a week, so we finally set out to do something about it. To speed up our blog deployments, we devised a way to take advantage of Gatsby's Incremental Builds using Docker in GitHub Actions.
Gatsby's Incremental Builds
Gatsby released Incremental Builds in Gatsby V3 and it's great for decreasing build times. As stated on their site, "an incremental build is a build of Gatsby that generates only the subset of HTML files that needed to be updated based on the changes made to the site." This means that after an initial build, which will be the slowest, subsequent builds will be much faster because Gatsby will only need to build what's changed since the previous build.
This worked great for us locally. If we ran gatsby build on our local computer, Gatsby would generate a .cache directory containing it's build cache, as well as the public directory of static files it serves when running. Then, if we make a change to the blog and run gatsby build again, the command finishes super fast since the .cache and public directories were already created and populated with most of the output the first time we ran build.
But, whenever we ran gatsby build in the context of GitHub Actions during a deployment, we'd never benefit from incremental building. In that environment, gatsby always performed the super slow initial build every time.
The reason we never got incremental builds within GitHub Actions is because we use GitHub Hosted Runners for all of our GitHub Actions workflows. These runners are essentially fresh hosts and environments that come with an admittedly solid number of dependencies pre-installed for convenience, but no persistent storage that lives beyond a job run, let alone a workflow run.
To tackle this problem and speed up build times, GitHub Actions does provide the actions/cache action which is used for caching dependencies and build outputs—kinda exactly what we wanted for this project (or so we thought). Turns out our embedding of Gatsby within Docker made it a bit tricky to take advantage of this caching action, but we came up with a couple of bad ideas to try and do so anyway.
How NOT to cache Gatsby builds
In the GitHub Actions context, the gatsby build command we run isn't actually executed in the shell of the runner. Instead, it's defined in our blog's Dockerfile and executed during the docker build step. So, right off the bat, we needed to come up with a way for the actions/cache to cache directories that only existed in the Docker context.
FROM node:18.13.0 as builder
RUN mkdir build
WORKDIR build
COPY . .
WORKDIR packages/blog
RUN yarn
RUN yarn compile
# `yarn build` runs `gatsby build`
RUN NODE_OPTIONS="--max-old-space-size=6000" yarn build
FROM gatsbyjs/gatsby:d5fdc9e9
ARG BUILD_SCM_REVISION
RUN mkdir -p /pub/blog/
COPY /build/packages/blog/public/ /pub/blog/As you can see in the above definition, we COPY the blog source into the Docker build context and run yarn build, which just runs gatsby build. After building, Gatsby's public directory is copied to a generic Gatsby base image, which, when run, serves the /pub/blog/ static directory.
This COPY command gave us our first idea for trying to use incremental building during deploys. The idea was to run gatsby build in a runner's shell before building the Dockerfile. Since the GitHub runner and the base Docker builder image are both linux based, we thought, (I thought), there might be a chance we could build the blog outside the Docker context, then just COPY the .cache and public directories over to the Docker context and it might "just work." If this did work, we could then use the actions/cache to cache .cache and public for our deployment workflow and violà! We'd have a faster deployment time.
But this did not work.
This first bad idea got us thinking a bit more. It seemed like what we really wanted here was to create some empty directories on the runner, then mount those into our Docker context. Doing this would ensure gatsby build generates the correct output for the Docker environment and container file system while also persisting the outputs to the runner's disk. This would make these mounted directories accessible to the actions/cache, and we'd be in business.
For those familiar with Docker, mounting directories to a container is pretty easy. You just do docker run -v /local/path:/path/on/container ... . The problem, though, if you haven't noticed already, is that volume mounting is actually a docker run option, not a docker build option.
As it turns out, there is no way to mount volumes at build time with Docker. Well, at least not with a first class -v option like the docker run command supports.
Docker has a documentation page for optimizing builds and it refers to an option to use a specialized cache called a "dedicated Run cache" that provides caching between runs. From the documentation:
RUN \
\
apt-get update && apt-get install -y git"Using the explicit cache with the --mount flag keeps the contents of the target directory preserved between builds. When this layer needs to be rebuilt, then it’ll use the apt cache in /var/cache/apt."
Reading the above information, we came up with our next bad idea. Largely based on the use of --mount in the above command, we assumed that with this syntax Docker was creating a volume backed by a host directory and attaching it to the container. This must be, we reasoned, (I did), how Docker does the caching between builds. To use the actions/cache, then, we'd just need to point the action at the directory Docker is uses as the volume.
As it turns out, though, and as docker volume inspect would reveal during experimentation, Docker isn't created a volume when the dedicated run cache --mount syntax is used. Likely, Docker is just caching /var/cache/apt in another layer in its build cache.
"What about just caching Docker's build cache with the actions/cache then?" you might be wondering. Great question, but it actually doesn't get us any closer to taking advantage of Gatsby's Incremental Builds. Even if we cache the blog's Docker cache in GitHub Actions, every modification to the blog source would trigger a rebuild of the Docker layer that runs the gatsby build command. So we'd still be generating Gatsby outputs for the first time, every time.
After experimenting with these bad ideas and lots of cursing, we, (Aaron), had a pretty good idea. Looking at our blog Dockerfile again, we thought, "why don't we make the base docker image of the blog contain the latest gatsby build outputs? Then, after a deployment, we can update the base docker image with the newer outputs."
If you're unfamiliar, we have a term for the infinite nesting of Docker containers here at DoltHub—it's called dockerception. And, the cool part about our latest dockerception strategy is that even though it doesn't use the actions/cache action at all, it lets us achieve our goal and benefit from incremental builds during our blog deployments. Here's how we did it:
What works
First, we created a Dockerfile for our base Gatsby cache image.
FROM node:18.13.0 as builder
RUN mkdir build
WORKDIR build
COPY . .
WORKDIR packages/blog
RUN yarn
RUN yarn compile
# `yarn build` runs `gatsby build`
RUN NODE_OPTIONS="--max-old-space-size=6000" yarn build
FROM scratch
COPY /build/packages/blog/.cache /cache
COPY /build/packages/blog/public /publicNotice it looks pretty similar to our original blog Dockerfile. This docker image still runs yarn build (which is gatsby build), but instead of copying the output public directory to a base Gatsby docker image, we copy both public and .cache to a scratch Docker image. Assuming we build this image for the latest blog content, which we do, the final image here will have all the Gatsby build outputs at /cache and /public.
Next, we push this image to an ECR repository as dolthub-blog-cache:latest so that we can refer to it in our original blog Dockerfile as the base image. Here is our updated blog Dockerfile:
FROM dolthub-blog-cache:latest as cache
FROM node:18.13.0 as builder
RUN mkdir build
WORKDIR build
COPY . .
WORKDIR packages/blog
COPY /cache /build/packages/blog/.cache
COPY /public /build/packages/blog/public
RUN yarn
RUN yarn compile
# `yarn build` runs `gatsby build`
RUN NODE_OPTIONS="--max-old-space-size=6000" yarn build
FROM scratch as new_blog_cache
COPY /build/packages/blog/.cache /cache
COPY /build/packages/blog/public /public
FROM gatsbyjs/gatsby:d5fdc9e9
ARG BUILD_SCM_REVISION
RUN mkdir -p /pub/blog/
COPY /build/packages/blog/public/ /pub/blog/In this new version, before we run yarn build in the builder image, we COPY the two output folders from the base cache image to the place where Gatsby expects them. Then we run yarn build which sees both .cache and public, and now we get Gatsby's Incremental Build working. As a result, this step runs very quickly.
Just like in the original blog Dockerfile, we copy the public directory to the generic Gatsby image to be served at runtime, but we've added one additional step before that. In this updated Dockerfile, we define a new image called new_blog_cache that uses a scratch base. In this image, we copy the now updated outputs from the builder image that ran gatsby build.
This new_blog_cache image is then tagged and pushed to ECR as the new dolthub-blog-cache:latest, ensuring we always start our blog docker builds with the most up-to-date Gatsby build outputs. It also ensures that subsequent blog builds are incremental 🤠.
Conclusion
After these changes, our blog deployment times dropped from 30 minutes to sub 10 minutes! Doing this work was definitely been worth the effort and has been a huge improvement for our blog development cycle. In combination with ChatGPT, writing our three weekly blogs is practically effortless 😉. (Big shout out to Midjourney for the images used above).
